200L Medical Liquid Filling Machine – Pneumatic Filling Equipment Specifications

Filling Capacity: 60-200kg/drum
Filling Accuracy: 0.1%
Speed: Up to 60 drums (200L)/hr (depends on viscosity & feed rate)
Weighing System: Max. 500kg, resolution 50g
Installation Requirements:

• Level, sturdy concrete floor (thickness >15cm)

• Temperature range: -10°C to +45°C

• Relative humidity: <95% (non-condensing)
  Power Supply: 220V, 50Hz, 1.0kW
  Air Supply: 0.5MPa±0.1MPa, consumption 10m3/h
  Material Inlet: DN40 PN1.6MPa (HG20592-97), customizable
  Air Inlet: G1/2 female thread (for quick coupling)
  Material Inlet Pressure: 0.2–0.6MPa (depends on fluid properties)

Key Features

? Explosion-proof design (Ex d IIB T4 standard)
? Anti-drip nozzle prevents spills
? Dual-stage filling (fast + fine mode for high accuracy)
? Auto tare function ensures precise net weight
? Emergency stop for safety
? No-fill protection if nozzle misaligned

Operation & Applications

Process: Manual drum placement → Auto filling → Manual removal
Industries Served: Chemicals, paints, adhesives, resins, lubricants, inks, cosmetics, and more.

After-Sales Service

1. Free installation, debugging, and training (on-site or remote).

2. Detailed manuals and instructional videos provided.
