Introduction

1.For the filling of square barrels and drums below 100kg, the system adopts programmable PLC control, with full Chinese guid- ance and easy operation;

2.The filling head extends into the barrel mouth and automatical- ly exits when filling is completed. If the filling head is not aligned with the barrel mouth, it will automatically return;

3.The filling gun is made with integral technology to prevent dripping and splashing; the quick-release connector is easy to disassemble and clean;

4.The system target value can be set freely, and the height of the filling gun is adjustable, suitable for rapid filling of packaging barrels of various specifications;

5.Equipped with a large and small ball width group and a double-stage filling gun, the four-stage filling design of large, medium, small and trace quantities makes filling more accurate;

6.Filling is prohibited without a bucket on the weighing platform, and differential pressure zero-time bucket collision protection is provided;

7.Net weight/gross weight (automatic tare for each barrel) Two filling methods are automatically selected;

8.One-click operation, easy to use; multiple windows display filling volume, number of barrels, cumulative volume and other information;

9.There is a signal indicator light for real-time display, and an automatic alarm if the deviation is exceeded;

10.It has good stability,reduces losses,saves costs,improves operating efficiency and reduces manual operation pressure.

Product Parameters

Product Parameters
Model	GZM-30-1PT
Filling range	10-60kg
Power	AC220V±10%50hz
Air source	0.5mpa
Explosion-proof	EXIDIIRT6
Filling accuracy	0.02%
Speed(can/min)	2-4 barrels (1000L)
Filling station	1
Material	sus304/316





Installation Instructions

Main structure and working principle


1.Computer quantitative filling machine has feeding system, weighing system frame pneumatic control control system without power raceway and so on.

2.Feeding mode: the requirement of continuous and stable feeding (feeding pump pressurized feeding) feeding mechanism by solenoid valve through the cylinder to perform fast and slow feeding.

3.Filling method: ordinary conventional filling and lifting and diving filling (according to the needs of the order to choose).

4.The weighing platform is equipped with unpowered roller and frame support and filling system pneumatic control system: control fast and slow feeding valve in the process of using the weighing platform is not allowed to be subjected to additional external forces.


Shanghai Guangzhi Automation Equipment Co., Ltd. is a professional production and sales of packaging machine, filling machine factory, our company is located in Shanghai Songjiang Industrial Zone, covers an area of 5000 square meters, adjacent to the G60 science and innovation corridor, has rich industry experience, excellent human resources, excellent technical ability.

Since its establishment in 2010, our company has been committed to R & D, design, production to make customers more satisfied with the products, to provide quality after-sales service system, in the continuous efforts of all staff, our equipment is not only in the country chemical, construction and other industries have made achievements, but also exported to 49 countries around the world, and set up agents in South America, East Asia, Africa, more with the world.


Why choose us

1. Packaging solution we provide professional packaging and logistic service for your option. With plenty of experience and carefully treatment, we make sure the machinery delivery to you is good useful.

2. Pre-sale Service. pre-sale service will provide by our sales engineers and electrical engineers. offering complete bundle of packaging solutions and professional rationalization proposals and pre-sale testes.

3. After-sale service we provide free parts and parts delivery, when manufacture defects has been detected during normal operation(vulnerable parts not included)under warranty period(one-year warranty )as well as after-sale service of low cost. Free training course will be given to your technician at our factory site in Shanghai China.

Shipping Scenario and Component Brand
