De-stacker
Shanghai Guangzhi’s De-stacker unloads 120 cases/hour from pallets. Vision-guided layer separation, adaptive grippers & collision avoidance. CE/UL certified.
- Brand: glzon
- Model: GZM
Shanghai Guangzhi’s De-stacker unloads 120 cases/hour from pallets. Vision-guided layer separation, adaptive grippers & collision avoidance. CE/UL certified.
Shanghai Guangzhi Automation’s De-stacker revolutionizes production line feeding – unloading 120 cases/hour from stacked pallets with ±0.5mm precision. Combining 3D vision-guided layer separation, adaptive vacuum grippers, and real-time collision avoidance, it achieves 99.8% pick success while handling diverse containers (cartons, crates, pails) from 5-50kg in food, beverage, and FMCG operations.
1. Vision-Guided Layer Handling
System | Technical Advantage |
---|---|
3D Time-of-Flight Camera | Detects layer height (±0.2mm) |
AI Pattern Recognition | Identifies mixed SKU arrangements |
Collision Mapping | 0.1s path replanning for damaged stacks |
2. Adaptive Material Handling
Multi-Gripper System:
Vacuum pads (50-500 mbar adjustable)
Mechanical fingers for unstable loads
Force Control:
5-100N clamping pressure control
Fragile item protection mode
3. Industrial 4.0 Integration
OPC UA Connectivity:
Real-time OEE tracking (uptime/pick rate)
ERP synchronization (SAP/Oracle)
Predictive Maintenance:
Vacuum pump health monitoring
Belt wear analytics
Parameter | Standard Model | Heavy-Duty Model |
---|---|---|
Throughput | 120 cases/hour | 90 cases/hour |
Case Weight | 5-30kg | 10-50kg |
Case Dimensions | L: 200-600mm × W: 150-400mm | L: 300-800mm × W: 200-500mm |
Pallet Height | Max 2.4m | Max 3.0m |
Positioning Accuracy | ±0.5mm | ±0.7mm |
Power | 480V/60Hz, 5.5kW | 480V/60Hz, 8.2kW |
Air Consumption | 100L/min @ 0.6MPa | 150L/min @ 0.7MPa |
Footprint (L×W) | 3500×2800mm | 4200×3200mm |
Food & Beverage
Washdown Design (IP69K):
Stainless steel 316L construction
Food-grade seals (FDA 21 CFR)
Anti-Microbial Grippers:
Silver-ion coated surfaces
Chemicals & Lubricants
ATEX Zone 2 Option:
Explosion-proof components
Static-dissipative materials (<10? Ω)
Spill Containment:
Integrated drip trays
E-commerce Fulfillment
Mixed-SKU Handling:
AI-powered irregular stack processing
Auto-height adjustment for polybags
15" HMI with Digital Twin
Real-time visualization:
Pallet layer mapping
Vacuum efficiency analytics
Energy consumption
Pre-programmed profiles:
50+ preset container types
Safety System (SIL2)
360° safety laser scanner (ISO 13856)
Speed reduction in human proximity
Emergency-stop redundancy
US Beverage Plant Case:
Challenge: Manual unloading caused 3% product damage
Solution: Vision-guided de-stacker with force control
Results:
? 99.8% pick success rate
? Zero product damage
? ROI in 10 months
Certifications:
CE EN ISO 10218-1
ANSI/RIA R15.06
UL 508A (North America)
ISO 13849 PLd
Advanced Modules:
Module | Function |
---|---|
Conveyor Synchronization | Matches line speed (0.2-2 m/s) |
Barcode Scanner | Real-time SKU verification |
AR Remote Assist | HoloLens-guided maintenance |
Carbon Footprint Tracker | ISO 14064-compliant reporting |
24/7 Global Support:
Remote diagnostics via IIoT gateway
Critical Spares Dispatch ≤48h:
Vacuum generators
Vision cameras
Servo drives
Lifetime cycle optimization
APPLICABLE BARREL TYPE
