Shanghai Guangzhi’s Semi-Auto Pallet Filling Machine features a motor-driven conveyor, 18 pallets/hour throughput & adjustable height. Cut labor costs & boost palletizing precision. CE/ISO certified.
Revolutionize Palletizing Efficiency
Shanghai Guangzhi Automation’s Semi-Auto Pallet Filling Machine integrates a motor-driven conveyor system to deliver precision, speed, and ergonomic safety in medium-to-high-volume palletizing. Designed for boxes, sacks, and containers, it bridges the gap between manual labor and full automation – reducing costs by up to 60% while ensuring stack consistency. Ideal for warehouses, manufacturing plants, and logistics hubs.
Motor-Driven Conveyor System
Powered rollers with variable speed control (0–15 m/min) for smooth product transfer.
Zero back-pressure accumulation prevents product damage.
Ergonomic Height Adjustment
Hydraulic lifting platform (700–1,000 mm range) adapts to pallet layers and operator height.
Intelligent Control Panel
Touchscreen PLC with pre-set patterns (brick, column, pinwheel) and custom stacking programs.
Heavy-Duty Build
Carbon steel frame with anti-corrosion coating (load capacity: 1,200 kg).
Safety Ecosystem
Emergency stop, photoelectric barriers, and non-slip grating. Complies with CE/ISO safety standards.
| Parameter | Specification |
|---|---|
| Machine Type | Semi-Automatic Pallet Filler |
| Conveyor Mechanism | Motor-Driven Roller (MDR) Conveyor |
| Conveyor Width | 800 mm (Customizable: 600–1,200 mm) |
| Loading Height Range | 700–1,000 mm (Hydraulic Adjustment) |
| Max. Pallet Size (L×W) | 1,200 × 1,200 mm |
| Throughput Capacity | 12–18 pallets/hour |
| Power Requirements | 220V/380V AC, 50/60 Hz, 1.8 kW |
| Air Pressure | 0.6 MPa (Optional pneumatic assist) |
| Machine Dimensions | 3,200 × 1,600 × 1,600 mm |
| Weight | 720 kg |
| Noise Level | ≤75 dB(A) |
Food & Beverage: Stacking canned goods, beverage cartons, frozen product boxes.
Chemicals/Pharma: Palletizing sacks of granules, sealed chemical drums.
Logistics/E-commerce: Automated loading of parcels, mail bags, and mixed-size boxes.
Agriculture: Bagged fertilizers, seed packs, feed sacks.
Labor Savings: 1 operator can manage 15+ pallets/hour.
Zero Product Damage: Gentle handling with MDR conveyor.
Quick ROI: Payback period under 12 months.
Easy Integration: Fits existing production lines; minimal training required.
